DeZURIK Switches and Position Transmitters

Design & Construction

DeZURIK can provide mechanical or proximity switches on PowerRac, Compak, Diaphragm, T-Series, G-Series and MG-Series actuators. Position switches can be ordered separately or combined with a position transmitter in one enclosure. They can be mounted directly to DeZURIK valve actuators or to positioners.

The enclosure is epoxy coated, anodized aluminum. The explosion proof, corrosion resistant and water-tight enclosure is available in Nema 1, 3, 4, 4X, 5, 6, 7, 9, 12 & 13 ratings. A screw-on cover allows easy access to adjust switch settings. Settings of less than 1° are easily accomplished with a hex key wrench. As standard, the enclosure is equipped with two conduit connections.

Open and closed position is prominently displayed in a wide-angle viewing area. A prewired and labeled terminal strip enables quick, convenient attachment of field wires.
