SIZE RANGE:
2-24″ (50-600mm) with larger sizes available on application
PRESSURE RATING:
Standard pressure rating on 2-16″ valves is 150 psi CWP (1030kPa) and 18-24″ is 100 psi CWP (690 kPa), with higher pressures available with optional gate materials.
BODY MATERIAL:
Cast body is available in Ductile Iron, Carbon Steel and various Stainless Steel or higher alloy materials.
END CONNECTIONS:
Full flanged design with flange drilling per ASME B16.5 Class 150, DIN 10 and DIN 16; ISO 7005-1/PN10 and 7005-2/PN16; BS 4504/PN10 and BS 4504/PN16; AS 2129 Tables D and E; and SANS 1123-1000 and SANS 1123-1600
TEMPERATURE RATINGS:
to 177°F (81°C) as standard, and up to 300°F (150°C) with high temperature optional seat materials.
Knife Gate Valve Styles, Applications, Operating Conditions & Installations Performance
Download Resource
Material Selection Guide
DeZURIK’s Material Selection Guide program makes it quick and easy to determine which metals or elastomers are suggested as suitable for application in a specific corrosive media. Click the icon above to learn more or use the program.
