SIZE RANGE:
3-168″ (80-4300mm)
TEMPERATURE RANGE:
to 290°F (143°C)
AWWA CLASS:
75B, 150B, 250B
PRESSURE RATING:
75 psi (520 kPa); 150 psi (1030 kPa); 250 psi (1700 kPa)
BODY MATERIAL:
Cast iron, ductile iron, carbon steel, stainless steel
END CONNECTIONS:
Flanged, Mechanical Joint
ACTUATOR TYPE:
Lever, handwheel, chainwheel, square nut, cylinder, electric motor
SPECIAL CONSTRUCTION:
Specially designed packages for Pump Check control applications are also available.
Alpha I
Alpha-I is a control valve sizing program that performs sizing calculations for DeZURIK control valves based on your process conditions. Click the icon above to learn more and download the program.
Material Selection Guide
DeZURIK’s Material Selection Guide program makes it quick and easy to determine which metals or elastomers are suggested as suitable for application in a specific corrosive media. Click the icon above to learn more or use the program.
250 psi Class AWWA Butterfly Valves 3-18″ Flanged End & 3-20″ Mechanical Joint End – Specification 43.01-7
Download Specification
250 psi Class AWWA Butterfly Valves 20-54″ Flanged End & 24-48″ Mechanical Joint End – Specification 43.01-11
Download Specification
AWWA Butterfly Valves Flanged End 24″ & Larger and Mechanical Joint End 24-48″ – Specification 43.01-2
Download Specification
Valve Manuals
D10386 – DeZURIK 3-20″ BAW AWWA BUTTERFLY VALVES WITH TRANSFER MOLDED SEAT
Download Instruction Manual
Actuator Manuals
D10505 – DeZURIK G-SERIES (6B/12A) MANUAL ACTUATOR – BAW BUTTERFLY VALVES
Download Instruction Manual
